MM: Nigel, in what context did you start evaluating the use of disposable technologies?

 GSK operates two aseptic vial and two syringe facilities, both using fixed and mobile stainless steel systems. These filling systems are not flexible enough to respond to the needs of a fast growing, varied product portfolio. The evaluation of disposables for final filling had already started at GSK, but the acceleration was precipitated by the need to rapidly fill a large quantity of vials for the flu pandemic because we did not have sufficient capacity with the existing setup.

MM: I understand that one factor that motivated you to switch to disposables was that cold fill products challenged the integrity of hard-piped steam-sterilized stainless steel systems.

 The thing that puts a lot of strain on the joints in the stainless steel systems is the polytetrafluoroethylene (PTFE) gaskets. These plastics do not have a cold flow memory and so do not react well when being heated to 121 °C for sterilization purposes, then to 5 °C for filling. There have been some problems with leakage over the years.

But even though cold fill products provided the greatest risk from the integrity point of view, there were many other reasons for the need for change. Stainless steel is fine when you are working with one dedicated product, but as we move to filling multiple biopharmaceutical products, the cleaning and sterilization issues rapidly become unwieldy. As the needs of our facility were changing and the regulatory qualification requirements for operations were increasing, it was becoming increasingly challenging to prove that there was no risk of cross contamination.

MM: You talk about the cost and capacity loss through qualification and routine steam-in-place (SIP) as one of the key challenges when working with traditional systems.

 When you carry out this analysis, you rapidly realize that the opportunities to improve efficiency, increase productivity, and reduce cost are huge. The time required for cleaning and sterilizing stainless steel; the space and money required for dedicated areas for clean and dirty vessel storage; the downtime required for cleaning, steaming, and product changeover; the massive energy consumption required to generate thousands of liters of water for injection (WFI) to clean and steam equipment, and the cost to make the WFI, are all highly time consuming and offer the potential for efficiency improvement.

Another key concern for us with the traditional systems was the complexity of operation and the associated level of grade A intrusions. With the existing arrangement using restricted access barriers (RABs), the doors between grades A and B would be open taking out and replacing equipment, and so on.

MM: What was the timeline for resolving these issues and implementing disposables?

 The project started in June 2009 and we needed to start filling in September 2009.

MM: How was the project managed? What type of team did you put in place?

NB: The new product introduction department set up the URS, working in collaboration with the quality and engineering departments. Nigel Wood, our engineering project manager, played an important part, particularly looking at the integration of the Bosch system, as did our quality assurance (QA) department which took a pragmatic approach to making sound, risk-based decisions. We also worked in close collaboration with the Millipore Mobius experts.

Figure 1.  Getinge La Calhene DPTE aseptic transfer system with disposable beta port for transfer of pre-assembled manifold bags assembled with Bosch needles

We carried out a full critical review of all aspects of the filling systems and identified many areas of over complication. We challenged each of these aspects with local QA, then Millipore Mobius expert advisors, and then with the MHRA regulators. We took the approach that every item, regardless of its excellence or complexity, has a failure rate. Thus any reduction in items will have a beneficial effect, and many component parts were removed or at least reduced in complexity.

Other principles were that the product passage from point 1 to 2 should be as simple as possible with as few manipulations as possible (to reduce training and error rates) and wherever practical, as few grade A manipulations as possible. No aseptic connections (including needle assembly) means no SIP to point-of-fill, and minimal grade A intrusions. Our other main motto is, "where there are connections, use the best available."

Our approach on such a project is to work hand-in-hand with the end-user, a collaborative approach aimed at finding the best overall solution.

DISPOSABLES SELECTION  AND IMPLEMENTATION

MM: How did you evaluate the operational aspects of the technology and the cost of the options? How did you go about risk mitigation?

 If it hadn't been for the pandemic, the selection and implementation of disposables would no doubt have taken twice as long. In this situation, convincing the sponsors was somewhat quicker than in a normal situation. QA pragmatism through risk assessment also helped immensely.

One of the key technologies we selected was the Millipore Mobius magnetic drive mixer for bulk drug formulation. We had already done previous testing with this system and found it to work efficiently. The Millipore STS connector was used to secure the sterile connection of the irradiated filter in the grade C environment. In both cases, we went through a series of trials and training, using 10 assemblies for each connection for each process step. It is important that the operators are trained to make the connection, because if you don't make the final click properly it can leak. We chose 50-L bags from Sartorius Stedim Biotech for the bulk drug hold. We selected the Sartorius Stedim bags because we preferred the integrity testing methodology that they have developed. We also carried out a full risk assessment using failure mode effect analysis (FMEA).Other key technologies included the Getinge La Calhene aseptic transfer system, which was premounted with the disposable beta transfer port to allow aseptic transfer of the seven pre-assembled manifold bags mounted with the Bosch needles into the RABs.

Figure 2. Bosch single-use filling needles. GSK's use of Bosch needles began early in the development of the Bosch systems. The Bosch manufacturing process has been improved to control all aspects of quality control, including chemical and microbial levels.

The Millipore team worked to rapidly qualify the assembly of the Bosch needles on the manifold—not a simple task when ensuring the safety of the disposable assembly prepacked with stainless steel needles. The peristaltic pump filling systems from Groninger and Bosch were selected for their high level of accuracy and simplicity. We also work with ready-to-use presterilized stoppers from Helvoet & West Pharma, again eliminating washing requirements.

Cost was not the primary concern for pandemic flu. Time to get a solution and flow path security and sterility were the primary drivers. For other applications, GSK had a cost target, but was flexible with this as they learned of the operational efficiencies they would gain in using a single-use solution.

MM: Were procurement supply chain issues a consideration?

 The pandemic has clearly stretched the global supply of producers and manufacturers. Within our organization, there are strong supply chain management groups with regular reviews and audits of suppliers. We have particularly rigorous controls in place and also exchange a great deal with colleagues in the vaccines division who have many years experience with disposables selection and implementation.

Our client voiced concern about single sourcing from Millipore. Millipore has met with several clients to review our strategy around this critical area and is taking action such as developing specific bag holder systems that facilitate the deployment of bags from alternate vendors.

MM: What did you see as the biggest challenges with single-use systems?

 The fact that we are contracting out the sterility assurance, cleanliness, particulates, and endotoxin control to a third party requires careful auditing and supply agreements. We are of course concerned about the overall system integrity and the perceived weakness of polymeric materials. We were concerned about the reliability of sterile connections in terms of mold variation. Concerning the Bosch needles, we are concerned about ongoing control of the physical, chemical, and micro quality.

MM: One common concern when evaluating disposable technologies for final filling is the question of pre- and post-integrity sterile filter and disposable system testing. How was this handled?

Pre-use system and filter integrity testing is performed by Millipore. Package validation testing by ISTA 2A drop and vibration and post ISTA package integrity testing demonstrates that the system is integral pre-use.

 We then perform pre- and post-filter testing where appropriate.

MM: What do you see as the biggest limitations or risks when working with disposables in the context of final filling operations?

 Solvent-containing products are not ideal for disposables because of the potential for evaporative molecular loss through tubing by permeation. We had two preserved multi-dose products that couldn't be filled in a single-use setup.

Having said all of this, I think the best proof of the fact that these systems are a sound solution is that we have now filled 85 million doses and we have had no integrity issues and no sterility failures.

MM: In terms of the benefits, have you been able to measure efficiency and productivity improvements and related cost savings since implementing disposables?

 With the disposable setup, the amount of grade A intrusions for the wetted path assembly and strip down has been taken from 2 h to 0 using the Getinge La Calhene grade C to grade A door. This door has a disposable beta door that is premounted with the disposable assembly, and is pre-gamma sterilized and prepared by the vendor with all the relevant documentation. Also, with this arrangement there is no need for the operators to touch the needles, avoiding the need for SIP post-assembly. The system is considerably simplified. The regulators have commented that it could reduce aseptic risk.

The overall time savings are significant. The system preparation time is minimal, the system build time is 30 minutes versus 2 hours for the stainless steel system, sterilization before filling is 0 versus 3.5 hours, operator training time is 2 days versus 2 weeks, SIP qualification is 0 and no six-monthly requalification, the aseptic connections are 0 versus approximately 50 (which were SIP sterilized), and of course there is no cleaning validation. To sum it up, we previously required 36 hours for a campaign fill and we are now down to 12 hours!

In addition, we had a stretch target to reduce energy. Since implementing disposable technologies for final filling, our site energy usage has dropped, significantly reducing our carbon footprint. In addition, we have significantly reduced the carbon footprint and increased capacity by 40%. Validation and routine SIP are key contributing factors, but of course there are many other factors, as outlined earlier. We haven't yet carried out a full cost analysis, but again we expect the overall impact to be significant in terms of less water usage and less chemical usage. And of course the increased capacity means that the number of days gained in manufacturing capacity is huge.

MM: What are the key take home messages you have gained from this project?

 Disposables offer a platform-enabling simplification of many activities. The end-to-end solution will provide the biggest benefits, including reducing assembly time, limiting aseptic intrusion, and enabling modular use of set-ups, allowing for minimum hold and maximum flexibility. Consider all connections as highly critical, assume leakage will occur, and build in security. Lastly, control suppliers through quality and supply chain agreements.

All of our forecasts indicate that there is going to be an explosion in the need for vaccines. Previously we were constrained by capacity and now, thanks to disposable platforms, we can rapidly gear up to meet demand.

The track record and experience gained in the use of disposables in a good manufacturing practices (GMP) environment for active pharmaceutical ingredients (API) manufacture has led to an upsurge in interest in recent years in the use of disposable technologies in the fill–finish arena. Recent developments in disposable filling sets for small- and large-scale liquid filling lines, together with disposable rapid transfer port technologies has meant that, for the first time, a disposable fluid path from the formulation vessel to the vial or syringe can be established, thus realizing the full potential of the technology.

The case study confirms that the benefits seen in bulk API manufacture also are realized in the fill–finish facility, specifically with regard to reduced costs, reduced energy usage, and reduced labor.

  Based on the outcomes of this case study, the future for disposables use in the final filling arena has significant potential to simplify process operations. This would reduce process risk, significantly reduce carbon footprint, and save considerable time in process operations, notably through reducing the time required for assembly and eliminating the requirement for disassembly of equipment, eliminating time required for cleaning and steaming operations, thus increasing available capacity (in this case by 40%).

Although a full cost analysis was not carried out, it is clear that the cost savings are significant, notably in terms of the number of extra days of manufacturing that become available, along with significantly reduced WFI requirements.

Disposables Advisor

How this Big Pharma company successfully implemented disposable technologies in its manufacturing plant.

End-to-End Deployment of Single-Use Technology in Aseptic Filling of Vaccines at GSK

Membrane chromatography offers a good solution to the challenge of developing an efficient chromatographic procedure for plasmid DNA purification. The large convective pores of anion exchange membranes allow plasmid DNA to access all the anionic binding sites of the membrane at high flow rates. Here we demonstrate that the pIDKE2 plasmid can be purified from a recombinant

 lysate using a Sartobind D membrane combined with size exclusion chromatography to render material with 95% purity and an average yield of 50%. This process yields therapeutically suitable plasmid DNA that meets all regulatory requirements.

Gene therapy and DNA immunization are important and promising possibilities to successfully develop preventive and therapeutic strategies for various diseases. Thousands of people have already received plasmid DNA (pDNA) without serious adverse effects. In the last decade, an increasing number of clinical trials for gene therapies and vaccines based on pDNA have reached the final phases. However, the amount of highly purified pDNA that will be required for these products,

should they ultimately reach the market, has been largely underestimated. Commercial-scale processes for plasmid production must be able to manufacture grams or even several kilograms of purified pDNA per batch while meeting the quality standards required by the health authorities.

The chromatographic supports used in purifying such plasmids play a major role these processes, the development of which can be challenging.

  In particular, RNA removal is a challenge because its chemical composition and structure are so similar to those of pDNA, and because it is so abundant in crude plasmid preparations.

  Also, the large pDNA molecules adsorb only on the outer surface of the particulate supports, and consequently their capacity is very low—usually on the order of only hundreds of micrograms of plasmid per milliliter of chromatographic support.

Here we describe a procedure for purifying the pIDKE2 plasmid, which encodes the hepatitis C virus (HCV) core, E1, and E2 structural proteins, using a Sartobind D membrane (Sartorius-Stedim Biotech, Goettingen, Germany) at high flow rates. The quality of the pDNA produced using this membrane-based purification process was demonstrated using the analytical methods recommended in relevant US FDA guidance.

  The procedure delivers the pIDKE2 plasmid with an average yield of 50% and with 95% purity. The biological activity of the purified plasmid was confirmed

: vaccinated mice developed a positive antibody response against all HCV structural antigens—86.6% and 60% for the core and E2 proteins, respectively.

All the reagents used to make the buffers were purchased from Merck (Darmstadt, Germany) and Sigma (St. Louis, MO)

 G25 coarse chromatography medium, Sepharose CL-4B, and Sephacryl S-1000 were purchased from Amersham BioSciences (GE Healthcare, Piscataway, NJ).

. Co.120 comprises the first 120 amino acids (aa) of the HCV nucleocapsid protein, whereas E1.340 encompasses aa 192–340 of the viral protein.

  E2.680 comprises aa 384–680 of the HCV polyprotein and is obtained from recombinant

 DH10B cells harboring pIDKE2, a plasmid for DNA immunization expressing the first 650 aa of the HCV polyprotein from the 1b-Cuban isolate genotype,

  were grown overnight, at 37 °C, in 100 mL shake flasks containing 50 μg kanamycin/mL, at 250 rpm. The engineered

 was cultured in a 5-L fermenter (Marubishi, Tokyo, Japan) using a complex media containing 50 g/L of yeast extract in fed-batch mode.

The bacterial cell paste (typically 200 g) was re-suspended in 2.4 L of a buffer containing 61 mM glucose, 10 mM Tris–HCL, and 50 mM EDTA, at pH 8. Bacteria were lysed using a previously described procedure.

  The clarified lysate was concentrated five times on a tangential flow filtration (TFF) system (nominal molecular weight cutoff 100,000 kDa, 0.1 m

 ). All experiments were conducted keeping a constant transmembrane pressure (TMP) of 0.8 bar at 4 °C, using Sartocon Slice equipment (Sartorius-Stedim Biotech). To remove RNA, the concentrated clarified lysate was loaded on Sepharose CL 4B in a BPG 113 column equilibrated with 20 mM Tris–HCL, 3 mM EDTA, and 1.5 M (NH4)

Plasmid capture and elution using the Sartobind membrane was carried out after buffer exchange on a G25 matrix using 25 mM Tris, 10 mM EDTA, and 0.5 M NaCl, at pH 8 and a rate of 50 mL/min, to reach a conductivity of 45 ms/cm. The pDNA fraction was pumped at 150 mL/min to the membrane holder 91-D-01K-15-03. After loading the feeding solution, the membrane was rinsed with a pH 8 buffer containing 25 mM Tris, 10 mM EDTA, and 0.7 M NaCl. Bound plasmid DNA was eluted with a buffer solution containing 25 mM Tris, 10 mM EDTA, and 1.2 M NaCl at pH 8. Finally, the membrane was regenerated using 0.5 M NaOH. The pDNA polishing was achieved on Sephacryl S-1000 media on a formulation buffer of 20 mM NaH

, 1 mM EDTA, and 30 mM NaCl at pH 6.7, using a 50X K column (Amersham BioSciences) at 4.8 mL/min. Fractions containing more than 89% supercoiled pDNA were processed by TFF until reaching a concentration of 2 mg/mL as determined by the absorbance at 260, using a VivaFlow 200 system (nominal molecular weight cutoff 100,000 kDa, 200 cm

 ). The final pDNA was filtered (0.22 μm) before further analyses were performed.

Flow-through and eluted fractions were precipitated by adding one volume of 2-propanol for 15 min on ice and then centrifuged at 14,000

 for 10 min at 4 °C. The pellet was washed with 70% ethanol and centrifuged again at 4,000

 for 10 min. The pellet was air-dried for 5–10 min and dissolved in 50 μl 10 mM Tris–HCl at pH 8.5. Fractions prepared as described were tested for restriction digestion analysis, using transformation experiments, and analyzed by electrophoresis on 0.8% agarose gels. Binding capacity and pDNA purity were determined by measuring absorbance at 260 (A260) and 280 (A280) and expressed as the ratio A260/A280 in a low-salt buffer. The pDNA purified as reported was used as a positive control.

  Identity was evaluated by restriction endonuclease digestion using a panel of enzymes followed by analysis on agarose gels.

Mice immunization and biological activity

Fifteen female Balb/c mice (6 to 8 weeks old), purchased from CENPALAB (Havana, Cuba), were immunized intramuscularly three times every second week with 50 μg pIDKE2 + 5 μg Co.120, obtained using a method previously reported,

  or following the method described in the present paper. The presence of antibodies against recombinant HCV structural antigens were determined by ELISA, as previously described.

  The induction of antibody titers of above 1:50 against HCV structural antigens in >25% of the mice on day 42 was considered a positive response.

The most common method for isolating pDNA is based on alkaline treatment and detergent-mediated solubilization of the bacterial cell membranes. In the second stage, the pH of the solution is adjusted to a value close to 5.5 by adding potassium acetate.

  The change in the physicochemical conditions of the solution causes the renaturation and flocculation of the chDNA as well as the precipitation of protein–SDS complexes and cell wall debris.

  The insoluble material can then be separated from the liquor containing the pDNA by filtration or centrifugation; once separated, the liquor containing pDNA is subjected to downstream processing to recover and purify the product.

the insoluble material is separated from the liquor containing the pIDKE2 plasmid by centrifugation. Loading the crude lysate containing large amounts of impurities such as chDNA, RNA, proteins, and endotoxins directly to a chromatography matrix is not recommended; primary purification is essential.

  The clarified lysate containing the plasmid is concentrated five times using a TFF system; however, this step is not sufficient to remove all the RNA (Figure 1, lane 2). RNase is commonly added to degrade the RNA but this procedure is not recommended by regulatory agencies; consequently the RNA content in the clarified lysate is very high—about 25 times the amount of the pDNA in weight.

  In the present process, 100% of the remaining RNA is removed from the concentrated cell lysate during the first chromatographic step on Sepharose CL-4B, with 91% of the pDNA recovered.

  The analysis on the agarose gel shows that pDNA eluted in the void volume can be efficiently separated from RNA (Figure 1, lane 4).

pIDKE2 purification on a Sartobind D membrane

Large biomolecules such as pDNA bind only to the surface of traditional chromatography beads; hence, the capacity for pDNA is much lower than it is for small biomolecules which are able to access the full volume of the beads.

Figure 2 shows the chromatographic profile for the separation of pIDKE2 under the selected conditions. During loading, no significant amount of pDNA was detected in the flow-through at the high flow rate of 150 mL/min. We calculated the average dynamic binding capacity for 10 batches at 3.3 ± 0.8 mg pDNA per mL. This means that the capture of pDNA from

 lysate is more efficient and rapid using the Sartobind D membrane, which has a dynamic binding capacity between 4.1 and 2.5 mg pDNA per mL support using a flow rate of 4.3 column volumes per minute. This is a more desirable result than what can be achieved by conventional anion-exchange resins, which bind about 1 mg of pDNA per mL of resin at flow rates that typically are lower than 0.5 column volume per minute.

  Seventy percent of the pDNA was eluted with 90% purity as determined by agarose gel, and no RNA is found (Figure 1 lane 6, Table 1). In addition, the assays for proteins and endotoxins indicate that there was a reduction of these contaminants.

Table 1: Testing results of released purified pIDKE2 compared to specification limits.

The loading, washing, elution, and membrane regeneration procedures took place in 1.5 h. Thus, this approach significantly reduced the separation time and increased the throughput and productivity for pDNA recovery. The Sartobind D membrane was repeatedly used for 10 batches. After each run, the membrane was regenerated with 0.5 M sodium hydroxide, because of its high stability in alkaline solutions. During the process, no change in backpressure was observed, demonstrating the stability and reproducibility of the membrane.

The final purification step was similar to that reported previously

: pDNA fractions were pooled, concentrated to 2 mg/mL by tangential flow filtration, and finally filtered (0.22 μm). The purification steps render a final high purity pIDKE2 plasmid with an average yield of 50%. The yield is influenced also by the homogeneity of pDNA in the cells. A summary of the analytical specifications according to FDA criteria is shown in Table 2. The purified plasmid pIDKE2 had 95% purity.

Table 2: Plasmid recovery, yield, protein, and endotoxin reduction for the Sartobind D capture step.

Plasmid identity was confirmed by restriction enzyme digestion and its activity confirmed by an

 assay. The purified pIDKE2 plasmid induced a positive response against HCV core and enveloped proteins, with  87% seroconversion against Co.120 and 60% against E2.680 proteins, respectively.

Our process produces plasmid DNA (pDNA) with 95% purity, and the process fulfills all regulatory requirements and renders pharmaceutical-grade pDNA The content of genomic DNA is lower than 5 ng per dose, RNA is not detectable by agarose gel electrophoresis; endotoxin content is 0.77 EU per kg body weight, and the protein content is 4.1 μg per dose, which is lower than the limit established.

In conclusion, this process, which combines size exclusion and membrane chromatography, met the criteria of purity, robustness, and reproducibility required for manufacturing pharmaceutical-grade pDNA for human clinical trials.

 is the department head, both in downstream process development,

 is a specialist in analytical development, and

 is a researcher  in fermentation development, all at the Centre for Genetic Engineering and Biotechnology, Havana, Cuba,

 1. Urthaler J, Schleg R, Pogdornik A, Strancar A, Jungbauer A, Necina R. Application of Monoliths for plasmid DNA purification development and transfer to production. J Chrom A. 2005;1065: 93–106.

 2. Ayazy P. Scaleable processes for the manufacture of therapeutic quantities of plasmid DNA. Biotech Appl Biochem. 2003;37:207–18.

 3. Stadler J, Lemmens R, Nyhammar T. Plasmid DNA purification. J Gene Med. 2004;6:S54–S66.

 4. Limonta M, Márquez G, Rey I, Pupo M, Ruíz O, Amador-Cañizare Y. Plasmid DNA recovery using size exclusion and perfusion chromatography. BioPharm Int. 2008;21:38–48.

 5. Lemmens R, Olsson U, Nyhammar T, Stadler J. Supercoiled plasmid DNA: selective purification by thiophilic/aromatic adsorption. J Chromatogr B. 2003;784:291–300.

 6. US Food and Drug Administration. Guidance for Industry: Considerations for Plasmid DNA vaccines for Infectious Disease Indications. Rockville, MD: 2005 Feb.

 7. Dueñas-Carrera S, Morales J, Acosta-Rivero N, Lorenzo LJ, García C, Ramos T. Variable level expression of hepatitis C virus core protein in a prokaryotic system. Analysis of the humoral response in rabbit. Biotecnología Aplicada. 1999;16: 226–31.
